The c8100 is a 15W UHF single-frequency radio repeater designed to extend communication coverage for two-way radio systems. Featuring relay functionality, group communication support and rapid heat dissipation, it provides a cost-effective solution for improving signal coverage in warehouses, farms, factories, hotels and construction sites.
The R-8100 is a professional UHF signal relay station designed to enhance communication range and eliminate dead zones in radio communication systems.
Operating in the 400-470MHz frequency range, the repeater receives and retransmits radio signals on the same frequency, significantly extending communication coverage without requiring expensive infrastructure upgrades.
With a powerful 15W RF output and efficient heat dissipation design, the R-8100 provides stable long-term operation in demanding commercial and industrial environments.
It is ideal for organizations seeking a simple and affordable solution to improve communication coverage across large facilities, warehouses, farms, construction projects and outdoor work sites.
| General | |||
| Type | C8100 | ||
| Channel Capacity | 16 | ||
| Channel Spacing | 25kHz/12.5KHz | ||
| Working Voltage | DC12V | ||
| Frequency Range | 400-470MHz | ||
| Antenna Impedance | 50Ω | ||
| Channel Bandwidth | 250KHz | ||
| Spreading Factor(SF) | 7 | ||
| Air Speed | 10kbps | ||
| Launch Duty Cycle | 35% (approx.) | ||
| Output Power | ≤15W | ||
| Rated Audio Power | 1000mW | ||
| Audio Distortion | ≤5% | ||
| Receiver Sensitivity | 0.3uV/-117dBm(BER5%) | ||
| Antenna Type | Magnetic Base Antenna/Fiberglass Antenna | ||
| Power Supply | Adapter AC220V/110V To 12V /5A Or DC12V | ||
| Operating Temperature | -20℃ ~ +50℃ | ||
| Weight | 2820g | ||
| Size: Length*Width*Thickness(mm) | 300*250*170(Without Antenna) | ||
| Modulation Mode | LoRa(CSS) | ||
| Main Function | |||
| LED Display | |||
| Audio Broadcast | |||
| Encryption | |||
| 16 Channels | |||
| Co-channel Relay Function | |||
| Auto connect | |||
| Supports 30 Levels Of Jumps | |||
| High Anti-interference | |||
| High Penetration Capacity | |||
| High Confidentiality |
